Nvidia Quantum-3 2U C2P Adjoining XDR IB Switch - Q3200-RA 36 XDR Ports 18 OSFP cages per Switch - 4 Power Supplies
|
|
|
SKU: 920-9B34F-00RX-FS0
Quantum-3 based Two-Adjoining XDR InfiniBand Switches, Q3200-RA, 2U, with 36 XDR Ports over 18 OSFP cages per Switch, 4 Power Supplies (Power Cords Not Included), Standard Depth, Managed, C2P Airflow, Rail Kit More details... |
|
|
|
Nvidia Quantum-3 2U C2P Adjoining XDR IB Switch - Q3200-RA 36 XDR Ports 18 OSFP cages per Switch - 4 Power Supplies
|
|
| |
|
Product Details
|
NVIDIA Quantum-3 Q3200-RA InfiniBand Switch The Q3200-RA is a 2U, air-cooled InfiniBand switch system, purpose-built to meet the extreme performance and scalability needs of modern AI and HPC clusters. Delivering 57.6 Tb/s of aggregate throughput with ultra-low latency and enterprise-grade resilience, it is a cornerstone for next-generation exascale data centers. Key Specifications - Ports: 72 × OSFP 800 Gb/s InfiniBand
- Aggregate switching capacity: 57.6 Tb/s (bidirectional)
- Forwarding rate: 72 × 800 Gb/s = 144 Bpps
- Form factor: 2U rack-mountable, air-cooled
- Cooling: Airflow-optimized design with redundant hot-swappable fans
- Power supplies: 4 × hot-swappable, load-sharing PSUs
- Management: Dedicated out-of-band Ethernet management port + in-band support
- Latency: Sub-600ns port-to-port latency
- Reliability: Redundant PSUs, fans, and field-replaceable units
- Software support: NVIDIA UFM Enterprise, Telemetry, Adaptive Routing
- Topologies supported: Fat-tree, Dragonfly+, torus, and custom AI fabrics
- Security: Secure boot, authenticated firmware, role-based access control
- Compliance: RoHS, CE, FCC, UL/IEC standards
Technical Overview Switch ASIC NVIDIA Quantum-3 InfiniBand switch ASIC delivering 800 Gb/s per port, enabling congestion-free scaling for AI workloads. Performance 57.6 Tb/s of throughput with hardware-based acceleration for adaptive routing, SHARP in-network computing, and congestion control. Scalability Supports large-scale clusters with advanced topologies optimized for HPC and AI supercomputers. Reliability Hot-swappable components, N+1 redundancy, and monitoring tools ensure continuous operation in mission-critical environments. Environmental & Physical - Form factor: 2U standard rack unit
- Dimensions: 87.5 mm × 440 mm × 800 mm (approx.)
- Weight: ~28 kg (61.7 lbs)
- Operating temperature: 0 °C to 45 °C
- Storage temperature: –40 °C to 70 °C
- Humidity: 10% to 85% non-condensing
- Airflow: Front-to-rear or rear-to-front options (depending on SKU)
- Noise level: Data-center grade, < 75 dBA
|
|
|
|
|
|
